International Harvester M-2-4 4x4 Trucks For Sale

1943 International Harvester M-2-4 USMC 4x4  "Apache Junction"    $7,500

1943 International Harvester M-2-4 USMC 4x4 5378 "Buckeye"      $7,500

1943 International Harvester M-2-4 USMC 4x4 3990 "Tucson"       $7,500



World War II International Harvester Company Trucks

The International Harvester Company, IHC, often simply referred to as “International”, originates from the merger in 1902 of the McCormick Harvesting Machine Company and Deering Harvester Company with 3 other small companies specializing in agricultural mechanical equipment.  During World War II, IHC has attained the rank of 33rd supplier for the US military. Some of their productions were specific to the Marine Corps and for the US Navy. In the class of trucks “2 ˝ ton, 6×6”, the equivalent of the GMC CCKW, IHC produced a very successful truck: the M-5 H-6. 36,000 units were produced; it was equipped with Thornton differential locks on the rear axles, a Hendrikson design with walking beam.
In the class of trucks “1 ton Cargo Truck” IHC began by delivering the M1-4, only 231 units were produced, plus 892 as ambulances (1941-1943). Its successor, the M2-4, was more successful with 9,101 units produced in the Springfield, Ohio plant.

There were two versions: with and without winch. The chassis were different: the winch was not on a riveted addition to the chassis as on the GMC CCKW.
The letter M was for “military”, 2 indicating the payload of 2,000 lbs and 4 indicated a 4WD vehicle. M-1-4 was equipped with the 213 cubic inch engine “Green Diamond Engine” while the M-2-4 had a bigger engine of 233 cubic inch “Red Diamond Engine”. The tires were larger on the M-2-4 : 9.00-16 instead of 7.50-16.

The first M2-4 models were equipped with 6V electrical system, 12V later on and the wheels had 6 studs at the beginning of production, 5 later on.



Technical data

Engine: gasoline, 93hp, 6 cylinders in line, overhead valves

Transmission: 4 speed x 2 with transfer

Dimensions: 198" x 85" x 65"





International 2WD & 4WD Trucks For Sale

1979 International IH S-Series 1700 1724 6140 Cargo Truck  $3,500

1977 IHC 1600 "Chance"  $3,500

1980 IHC 1824 4x4 "Lee Creek"  $5,500













International 4x4 Trucks Sold

( Click on yellow title to the right of each photo for Truck info )

1960 International R-196 4x4  Sold !

1960 International V-196  Sold !

1968 International 4x4 Lufkin  Sold !

1974 International R200 Arkansas  Sold !

1974 International R200 Parts truck   Parted Out !

1978 IHC 1750 4x4 "Ryan"  Sold !

2005 International IH 4400 DT466 Fuel Truck 2800 Gallon Young Tank  Sold !
